Fuel Tank for Forklift

Forklift Fuel Tanks - Most fuel tanks are fabricated; nevertheless several fuel tanks are made by skilled craftsmen. Restored tanks or custom tanks could be found on aircraft, automotive, tractors and motorcycles.

There are a series of certain requirements to be followed when making fuel tanks. Typically, the craftsman sets up a mockup in order to know the correct shape and size of the tank. This is often done utilizing foam board. Next, design concerns are handled, consisting of where the outlets, seams, drain, baffles and fluid level indicator will go. The craftsman has to determine the alloy, temper and thickness of the metal sheet he would make use of to make the tank. When the metal sheet is cut into the shapes required, lots of pieces are bent so as to make the basic shell and or the ends and baffles used for the fuel tank.

Lots of baffles in aircraft and racecars contain "lightening" holes. These flanged holes have two purposes. They add strength to the baffles while reducing the weight of the tank. Openings are added toward the ends of construction for the drain, the fuel pickup, the filler neck and the fluid-level sending unit. Occasionally these holes are added as soon as the fabrication method is finish, other times they are made on the flat shell.

Next, the ends and baffles can be riveted into position. The rivet heads are often soldered or brazed in order to stop tank leaks. Ends could afterward be hemmed in and flanged and sealed, or brazed, or soldered utilizing an epoxy type of sealant, or the ends can also be flanged and then welded. After the soldering, brazing and welding has been completed, the fuel tank is checked for leaks.
